6-In-1 Dual Voltage Welder & 40A Plasma Cutter, Pulse MIG TIG MMA 180A
CUT: 30A
Rated Input Current: 110V:45A 220V:32A
Input Voltage / Frequency: 110/220V
model: MIG-350I
Product Description
This 6-in-1 dual voltage welder and 40A plasma cutter combines Gas MIG, Flux Core MIG, Pulse MIG, TIG, MMA and plasma cutting functions in one compact machine. Powered by advanced IGBT inverter technology, it delivers up to 180A welding output on 220V input and 120A on 110V input, with plasma cutting output up to 40A on 220V and 30A on 110V.
With a lightweight 9.28 kg design, this multi-process welding machine is ideal for metal fabrication, repair, maintenance and on-site work. It is suitable for both home users and professional workshops requiring flexible welding and cutting performance.
Product Specifications
Product Type
Input Voltage / Frequency
Rated Input Current
Output Current Range
Rated Duty Cycle
Inverter Technology
Efficiency / Power Factor
No-load Voltage
Welding Thickness
Usable Electrode / Wire Diameter
Insulation & Protection Class
Machine Dimensions
Package Dimensions
Net Weight
Gross Weight
6-in-1 Dual Voltage Welder & Plasma Cutter |
110V / 220V |
110V: 45A; 220V: 32A |
110V: MMA / MIG / TIG / Pulse MIG / Flux Core MIG: 120A; CUT: 30A |
40% |
IGBT |
85% |
65V |
0.3-10mm |
110V: Electrode: 1.6-3.2mm; Welding Wire: 0.8-1.0mm |
F |
440 × 200 × 350mm |
540 × 325 × 430mm |
9.28kg |
16.2kg |
Product Advantages
1. 6-in-1 Multi-Process Function
Supports Gas MIG, Flux Core MIG, Pulse MIG, TIG, MMA and plasma cutting in one versatile machine.
2. Dual Voltage Input 110V / 220V
Flexible dual voltage operation makes the machine suitable for both home users and professional workshops.
3. Advanced IGBT Inverter Technology
IGBT inverter technology provides stable arc performance, reduced spatter and improved working efficiency.
4. Suitable for Thin Sheet Welding and Heavy-Duty Cutting
Ideal for thin sheet metal welding down to 0.3mm with Pulse MIG, as well as cutting tasks up to 10mm with the 40A plasma cutter.
5. Advanced Pulse MIG Technology
The integrated Pulse MIG mode improves arc stability, reduces spatter and lowers heat input, making it ideal for stainless steel and carbon steel fabrication.
6. Portable Compact Design
With a net weight of only 9.28kg, the machine is easy to transport and convenient for on-site operation.
List of Accessories
3m 25mm² copper-clad aluminum 300A electrode holder cable with 35-50 quick connector
3m 25mm² copper-clad aluminum 300A ground clamp cable with 35-50 quick connector
15AK MIG torch, 3m, with one 0.8mm contact tip, one 1.0mm contact tip and wrench
One V-groove wire feed roller, 0.6-0.8mm
One K-groove wire feed roller, 0.8-1.0mm
3m transparent gas hose with hose clamps
QQ150 TIG torch, 4m, with 1.6mm, 2.4mm and 3.2mm collet holders, one gas lens, 4/5/6 nozzles, two torch head caps and one nut insulator
PT31 plasma cutting torch, 3m, with one set of electrode, cutting nozzle and protective shield
One gas regulator
One adapter connector, large American-style connector to small American-style connector
FAQ
Q1. What welding processes does this machine support?
This machine supports Gas MIG, Flux Core MIG, Pulse MIG, TIG, MMA welding and 40A plasma cutting, providing six functions in one compact unit.
Q2. Can it operate on both 110V and 220V power?
Yes. The machine features dual voltage 110V / 220V input, making it suitable for both home and workshop applications.
Q3. What is the maximum welding output current?
The maximum welding output is 180A under 220V input and 120A under 110V input.
Q4. What is the maximum plasma cutting current?
The machine delivers up to 40A plasma cutting output on 220V input and 30A on 110V input.
Q5. What materials can be welded?
It is suitable for welding carbon steel and stainless steel in a wide range of fabrication, repair and maintenance applications.
Q6. What wire sizes are supported?
The machine supports 0.8-1.2mm welding wire on 220V input and 0.8-1.0mm welding wire on 110V input.
Q7. What electrode sizes can be used?
The recommended electrode size is 1.6-4.0mm under 220V input and 1.6-3.2mm under 110V input.
Q8. Can this machine perform gasless welding?
Yes. It supports Flux Core MIG welding, allowing gasless operation without the need for an external shielding gas cylinder.
Q9. What makes Pulse MIG welding beneficial?
Pulse MIG technology helps reduce spatter, improve arc stability and lower heat input, making it ideal for thin-gauge steel and stainless steel applications.
Q10. What is the maximum welding thickness?
The machine is suitable for welding materials from 0.3mm to 10mm, depending on the welding process, material type and operating conditions.
